Hei-FLOW Ultimate 600 Peristaltic Pump
This peristaltic pump is ideal for pumping & dosing reproducibility and accuracy.
Accurate dosing is particularly important in the pharmaceutical, cosmetic or food sector. Comprehensible process conditions are a prerequisite for the safe conveyance of sensitive media.
In addition, an optional foot switch allows the pump to be operated in closed exhaust hoods. The parameters - speed, direction of rotation and on/off function - can be controlled externally either through the analog or digital interface.
In this model, you can choose between a single-channel or multichannel pump head.
Depending on the focus of the process, the following parameters can be set on the device: Speed, tubing diameter, flow rate display, metering volume, interval dosing and break times. The pump can be calibrated for optimum dosing results.
- Control speed, direction and on/off function via analog interface or digital RS 232 interface
- Control accuracy of 0.5%
- Individual calibration of flow volume and flow rate
- Pump operates clockwise or counterclockwise at a push of a button
- Digital read out of speed, tubing diameter, flow rate in mL/min, dosing volume, interval dosing and pause function
- Model can be connected to an optional foot pedal remote control via cable to start and stop your pump drive outside a closed fume hood. Foot switch enables dosing by foot pressure, allowing hands to remain free to perform other work, for example, to hold the tubing and the vessel
- This model is designed for only single-channel pump head
- Flow rate of 2.0 4,056 mL/min with single-channel pump head
- High speed range from 24 600 rpm
