Adam GFK-S 75H Bench and Floor Scale: 75 kg x 1 g
Model number: GFK-S 75H | Adam item number (MPN): 1050017061 | Also written as GFK-S75H or GFK-S-75H
Enhance your industrial operations with the GBK-S and GFK-S Bench and Floor Scales, designed for precision and efficiency in demanding environments. These scales are perfect for checkweighing, batching, parts counting, and general weighing tasks, making them indispensable tools for busy production warehouses and shipping facilities.
Built to withstand the rigors of industrial use, the GBK-S and GFK-S scales feature a robust grade 304 stainless steel weighing pan and a sealed keypad, ensuring protection against dirt and spills. This makes them ideal for messy food operations in bakeries or when handling chemicals in laboratories. The durable ABS plastic indicator housing further enhances their resilience.
The user-friendly design includes a full numeric keypad and a backlit LCD display with large, 40mm-high digits, ensuring clear visibility in any lighting condition. The display also incorporates a capacity tracker to prevent overloads, safeguarding the internal components. For added convenience, the indicator can be mounted on a pillar or attached to a vertical surface.
With built-in checkweighing lights and audible alarms, these scales provide immediate feedback on whether weights are within preset limits, streamlining quality control and manufacturing processes. The colour-changing backlight in checkweighing mode offers a quick visual cue for under, over, or acceptable weight limits.
Connectivity is seamless with an RS-232 interface for quick data transfer to computers and printers, and an optional USB interface for simplified communication. The scales also feature an auto power-off function to conserve energy and an external calibration option for maintaining accuracy.
Choose the GBK-S and GFK-S scales for reliable, versatile performance that meets the demands of your industrial setting, ensuring precise results and efficient operations every time.
Key features
- Colour-changing backlight in checkweighing mode to show if under, over or within acceptable limits
- Large, 40mm-high easy to read digits on a bright background
- Simple, 5-key operation allows for easy set up and use
- Solid ABS housing (Indicator) is durable for industrial use
- Large, grade 304 stainless steel pan allows swift cleaning
- RS-232 interface provides speedy connection to computers and printers
- Optional USB interface simplifies data communication
- Selectable language for printing
- 1:1,600,000 Internal counting resolution for precise results
- Auto power-off to save energy
- Hold function freezes the displayed weight, allowing time to elapse without losing the result
- External calibration allows for verification and adjustment with weights
- Capacity tracker built into display for easily monitoring possible overloads
- Adam Connect compatible for Bluetooth® data transfer to printers and PCs
- 5-year manufacturer's warranty.
Weighing modes and applications
- Weighing
- Parts counting
- Percentage weighing
- Checkweighing
- Check counting
- Accumulation
Technical specifications
| Brand / series | Adam GBK-S and GFK-S Bench and Floor Scale |
|---|---|
| Model number | GFK-S 75H |
| Manufacturer part number (MPN) / Adam item number | 1050017061 |
| Capacity | 75 kg (165 lb) |
| Readability | 1 g (0.002 lb) |
| Repeatability | 1 g (0.002 lb) |
| Linearity | 2 g (0.004 lb) |
| Pan size | 500 x 400 mm (19.7 x 15.7 in) |
| Weighing units | g, kg, lb, oz, lb:oz |
| Stabilization time | 2 seconds |
| Interfaces | RS-232, Optional USB |
| Calibration | External calibration |
| Display | Backlit LCD with capacity tracker with 1.6 in / 40 mm high digits |
| Power supply | AC adapter / Optional 6V dc 4.5aH |
| Operating temperature | -10° to 40°C / 14° to 104°F |
| Construction | ABS plastic indicator with die-cast aluminum base |
| Overall dimensions (W x D x H) | 400 x 620 x 860 mm (15.7 x 24.4 x 33.9 in) |
| Net weight | 13 kg (28.7 lb) |
| Warranty | 5 years (manufacturer) |
